| Technical Features |
· Protection Class |
: IP 55 (EN 60529) |
· Color |
: RAL 7032 Electrostatic Granulated Paint |
· Thickness |
|
Body |
: 2 mm |
Door |
: 2 mm |
Headgear |
: 2 mm |
Standart Features
· Openable Door with 120o Wide Angle
· Multipurpose Profiles increase resistance of door
· Detachable Screwed Straight Back Door.
· Project pockets
Optional Feautures
· Pieced installation plate (Additionals)
· Bases 2 mm
· Cariage Rings, Combination and Dislocation Equipments
· Door Fixing Mechanism
· Special Color
· Special Size
· Measurement Sections
STANDARD DIMENSIONS |
|
|
|
600 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
800 |
250 |
HP 0806025 |
350 |
HP 0806035 |
1000 |
300 |
HP 1006030 |
400 |
HP 1006040 |
1200 |
400 |
HP 1206040 |
500 |
HP 1206050 |
1600 |
400 |
HP 1606040 |
500 |
HP 1606050 |
1800 |
400 |
HP 1806040 |
500 |
HP 1806050 |
|
|
|
800 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1200 |
400 |
HP 1208040 |
500 |
HP 1208050 |
1600 |
400 |
HP 1608040 |
500 |
HP 1608050 |
1800 |
400 |
HP 1808040 |
500 |
HP 1808050 |
|
|
|
1000 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1200 |
400 |
HP 12010040 |
500 |
HP 12010050 |
1600 |
400 |
HP 16010040 |
500 |
HP 16010050 |
1800 |
400 |
HP 18010040 |
500 |
HP 18010050 |
|
|
|
1200 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1200 |
400 |
HP 12012040 |
500 |
HP 12012050 |
1600 |
400 |
HP 16012040 |
500 |
HP 16012050 |
1800 |
400 |
HP 18012040 |
500 |
HP 18012050 |
|
|
|
ÖLÇÜ BÖLMESİ ( YÜK. STANDART 360 mm) |
Height (mm) |
Deepth (mm) |
Product Code |
600 |
200 |
ÖB 6020 |
300 |
ÖB 6030 |
800 |
200 |
ÖB 8020 |
300 |
ÖB 8030 |
1000 |
200 |
ÖB 10020 |
300 |
ÖB 10030 |
1200 |
200 |
ÖB 12020 |
300 |
ÖB 12030 |
|
