| Technical Features |
· Protection Class |
: IP 55 (EN 60529) |
· Color |
: RAL 7032 Electrostatic Granulated Paint |
· Thickness |
|
Body |
: 2 mm |
Door |
: 2 mm |
Standart Features
• Openable Door with 120o Wide Angle
• Multipurpose Profiles increase resistance of door
• Detachable Screwed Straight Back Door.
• 6 pieces of deepth sledge and and connections equipment of installation plate.
• A design for EMC Application Usage.
• Project pockets
Optional Feautures
• Ventilating and Air Conditioning System
• Installation Plate 2 mm (Galvanized)
• Intallation Plate Sledges (Additionals)
• Pieced installation plate (Additionals)
• Bases 2 mm
• Cariage Rings, Combination and Dislocation Equipments
• Door Fixing Mechanism
• Air conditioning system for ceiling
• Special Color
• Special Size
• Measurement Sections
400 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1600 |
400 |
MD 1644 |
500 |
MD 1645 |
600 |
MD 1646 |
1800 |
400 |
MD 1844 |
500 |
MD 1845 |
600 |
MD 1846 |
2000 |
400 |
MD 2044 |
500 |
MD 2045 |
600 |
MD 2046 |
|
|
|
600 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1600 |
400 |
MD 1664 |
500 |
MD 1665 |
600 |
MD 1666 |
1800 |
400 |
MD 1864 |
500 |
MD 1865 |
600 |
MD 1866 |
2000 |
400 |
MD 2064 |
500 |
MD 2065 |
600 |
MD 2066 |
| |
800 mm width panels |
Height (mm) |
Deepth (mm) |
Product Code |
1600 |
400 |
MD 1684 |
500 |
MD 1685 |
600 |
MD 1686 |
1800 |
400 |
MD 1884 |
500 |
MD 1885 |
600 |
MD 1886 |
2000 |
400 |
MD 2084 |
500 |
MD 2085 |
600 |
MD 2086 |
|
|
|
ÖLÇÜ BÖLMESİ ( YÜK. STANDART 360 mm) |
Height (mm) |
Deepth (mm) |
Product Code |
600 |
200 |
ÖB 6020 |
300 |
ÖB 6030 |
800 |
200 |
ÖB 8020 |
300 |
ÖB 8030 |
|
